| WDW76 |
|
|
|
Specifications
| Fan (Per Fan) |
| Operation Voltage |
DC
10.2 ~ 13.8 V |
| Rated Voltage |
DC 12V |
| Rated Current |
DC
0.24A MAX. |
| Input Power |
2.88
WATT MAX. |
| Bearing System |
One
Ball One Sleeve Bearing |
| Fan Speed |
4200±15
% RPM |
| Air Delivery |
33.25±15
% CFM |
| Noise Level |
38±
2dB(A) |
| Fan Safety |
UL
Approved |
| Fan with RPM signal
output |
Yes |
| Heatsink |
| Dimension |
88
* 68 * 44 mm |
| Material |
Aluminum
Alloy 6063T5 |
| Clip |
| Material |
Lexan3412 |
| Thermal Interface |
High
thermal conductive interface |
| Material |
GW101 |
| Connector |
Molex
2510 / 2695 3Pin |
| Total Weight |
340
g |
|
|
|
