| TAK68 |
|
|
| Fan
|
| Operation Voltage |
DC
10.8 ~ 13.2 V |
| Rated Voltage |
DC 12V |
| Rated Current |
0.21 A MAX. |
| Input Power |
2.52
Watt MAX. |
| Bearing System |
One
Ball One Sleeve Bearing |
| Fan Speed |
4700±15
% RPM |
| Air Delivery |
23.3±15
% CFM |
| Noise Level |
36.8±2
Dba |
| Fan Safety |
UL
Approved |
| Fan with RPM signal
output |
Yes |
| Heatsink |
| Dimension |
62.1
x 66 x 75 mm |
| Material |
Aluminum
Alloy 6063T5 |
| Clip |
| Material |
SUS301 |
| Thermal
Interface |
High
thermal conductive interface |
| Material |
GW103 |
| Connector |
Molex
2510 / 2695 3Pin |
| Total Weight |
405
g |
| Package |
64
Pcs / CTN |
|
|
