| FRK50 |
|
|
| Specifications |
| Fan |
| Part
Number |
AFB0512HHB |
| Operation
Voltage |
DC
7 ~13.8V |
| Rated
Voltage |
DC
12V |
| Rated
Current |
DC
0.13A |
| Power |
1.56
Watt |
| Bearing |
Ball
Bearing |
| Fan
Speed |
6200
RPM +/-10% |
| Air
Delivery |
16.2
CFM |
| Noise
Level |
36
dBA |
| Fan
Safety |
CE,
UL, CSA Approval |
| Lock
Protection-Auto Restart |
Yes |
| Fan
with RPM signal output |
Yes |
| Heatsink |
| Dimension |
120.2mm
x 58.3mm x 34mm |
| Material |
Anodized
Aluminum Alloy 6063 |
| Clip |
| Material |
Steel
SK7 (Quality Metal Clip) |
| Thermal
Interface Material |
Thermal
Grease |
| Connector |
Molex
2510/2695 3 Pin |
| Thermal
Resistance |
0.403
C/Watt |
| Application: |
Supreme
Advantages |
| Suitable
for AMD K7 CPU |
Best
Patented Clip Design
Takes only 5 seconds to install
Best cooling performance
Thermal grease/pad included as a standard package to further enhance
the thermal conductivity performance. |
|
|
