CAK586
|
|
|
|
Specifications
| Fan (
Per Fan ) |
| Operation
Voltage |
DC
7 ~ 13.8 V |
| Rated
Voltage |
DC
12V |
| Input
Current |
0.69A
MAX. |
| Input
Power |
8.28W
MAX. |
| Bearing
System |
Two
Ball Bering |
| Fan
Speed(RPM) |
4900±15
% RPM |
| Max.
Air Delivery(CFM) |
68.51(MIN.61.45)CFM |
| Noise
Level |
48.5(MAX.
52.5)dBA |
| Fan
Safety |
UL
Approved |
| Fan
with RPM signal output |
Yes |
| Heatsink |
| Dimension |
70
x 66 x 40 mm |
| Material
|
COPPER
1100 |
| Mounting
Kit |
| Retention
Clip |
Steel
SK7 ( Quality Material Clip ) |
| Thermal
Interface |
High
thermal conductive interface |
| Material |
GW101/GW103 |
| Connector |
Molex
2510 / 2695 3Pin |
|
|
|
